STEAM HOSE

Dragon Breath® II Barber Pole Steam Hose is designed for steam applications to 406°F for saturated steam at 261 psi and 450° for superheated steam at 250 psi, Series 7285

Technical Specifications :

  • Hose I.D. (inch): 1/2 - 1 inch
  • Hose Outside Diameter:1 inch, 26.2 mm
  • Hose Reinforcement Material:Multiple Wire Braids
  • Hose Inner Tube Material:Black Chlorobutyl
  • Maximum Operating Temperature:450 °F Superheated Steam, 232 superheated steam °C, 208 Saturated Steam °C, 406 Saturated Steam °F
  • Minimum Bend Radius:7 inch, 178 mm
  • Cover Material:Black & Red EPDM
  • Weight:0.50 lb/ft, 0.75 kg/m
  • Minimum Operating Temperature:-40 °F
  • Maximum Operating Pressure:18 bar, 261 psi
  • Hose Inside Diameter:1/2 inch, 12.7 mm
  • Application:Manufacturing / Industrial
  • Media:Steam
  • Specifications Met:ISO 6134 (Type 2)

Download Catalog Here

RACOR FUEL FILTER

The Parker Racor Fuel Filter Water Separator Turbine Series is the most trusted line of fuel filter water separators on the market. The assembly’s three-stage filtration system effectively removes water and particulates from fuel, providing maximum protection of diesel engine components in applications where reliability is critical.

To meet the unique requirements of customer’s engines, Racor Turbine Series fuel filter water separators are available in a wide range of configurations. All models utilize Racor’s proprietary Aquabloc® filtration elements. Aquabloc® is a unique engineered media that incorporates pleat-spacing corrugations and a graduated pore structure to increase dirt-holding capacity and extend filter life. The media is waterproof and rustproof, capturing contaminants while the specially treated surface separates and coalesces water from the fuel.

Technical Specifications :

  • Product Series : Catdrige FF/WS, Industrial Turbine
  • For Fluid Ttype : Diesel Fuel / B20
  • Brand : Racor
  • Pump Type : An Electric Primer Pump is an available option for 900 and 1000 series only
  • Element Removal Clearance : 4 in/ 10.2 mm to 10 in/25.4 mm inch
  • Maximum Continuous Pressure : 15 psi / 1.03 bar

Download Catalogue Here

PARFLANGE F37

The Parflange F37 flanged connector system is utilising the orbital tube forming technology for tubing assemblies from 16 to 273 mm (1/2" to 10" Flanges) outside diameter. It is intended for tube wall thickness up to 9 mm and pressure ratings up to 420 bar. For those connections without the possibility to assemble a pre-flared tube or where manufacturing is limited, Parker provides the F37 Retaining Ring System. This System utilizes a Retaining Ring for flange retention along with a highly-engineered seal carrier for leak free performance. It is available as a high pressure version from 1 1/2" to 10" and as a newly developed SAE 1000 (50-70 bar) version. The Parflange F37 system corresponds to hole patterns according to ISO 6162-1; SAE J518; bore pattern 3000 (code 61), ISO 6162-2; bore pattern 6000 (code 62) and also ISO 6164 bore pattern. It is type approved by DNV, ABS and other major classification companies.

Innovative Sealing Solutions The F37 seal was developed especially for use with SAE flanges. These special seals guarantee high stability of form. Compared to standard O-Rings, their mechanical properties prevent gap extrusion, even when the flanges ”breathe” under pressure. The special profile of the F37 seal is ideally adapted to higher pressures or unsuitable surface finish of the flanges. As an alternative, connectors can be equipped with bonded seal rings.

Complete range for virtually all diameters The F37 system complements the EO-2 soft sealing technology for small tube diameters; it also complements the proven Parflange programme for the SAE product range. It offers the complete range of connectors, flange-to-flange, L-and T-Block connectors, flange-to-port, male and female thread flanges, flange bends, reducer flanges, ball valves, bulkhead flanges and manifolds on request.

Technical Specifications

  • Flange Size : 1"
  • Bolt Size : Standard
  • Assembly Includes : Flange / Insert Flat
  • Material : Stainless Steel and NBR
  • Port Type : SAE 6000 / ISO 6162-2
  • Tube Size : 25x2, 5

Download  Catalog Here

POLYFLEX HOSE

The hose assemblies are made from high-pressure hose and the corresponding fittings by Parker Polyflex and the company’s trained and certified distributors in compliance with Parker assembly instructions. They are pressure tested after completion. Upon customer’s request, the hose assemblies can be equipped with protective sleeves or other safety equipment such as containment grips.

The working pressures of both hoses and fittings are limited. In rare cases, fittings with a lower working pressure than the hose may be used. In this case the hose assembly bears an addition- al warning. For the application of the hose assembly, it is not the pressure stated on the hose but the pressure on the crimping shell and/or marking sleeve that is relevant.

Temperature Range :

• Operating temperatures ranging from -50°C up to +230°C • Best choice for dynamic applications even at very low temperatures • Full working pressure even at extreme temperatures

Download Catalog Here

MPI FITTINGS

Parker's MPI™ Series is an inverted two ferrule design engineered and manufactured to provide secure, tight, and leak resistant connections for small bore instrumentation applications up to 15,000 PSI.

Parker MPI™ Fittings are an inverted two ferrule, compression design. They are engineered and manufactured to provide secure, tight, and leak-resistant connections throughout industry, including off-shore oil and gas exploration platforms, research labs, and other facilities that require operating pressures in the range of 6,000 to 15,000 psi.

MPI™ Fittings are ideally suited to handle liquids, gases, or chemicals and can be used on a wide variety of tubing materials including cold drawn – 1/8 hard (unannealed) stainless steel tubing, annealed 2507 seamless tubing or instrument grade thick-walled annealed stainless steel. Every Parker MPI™ Fitting is supplied complete and ready to install.

Features/Benefits: • Front ferrule with corrosion-resistant Parker Suparcase® forms a seal between the tube, body and ferrule. It also provides a mechanical hold on the tube. • Back ferrule with corrosion-resistant Parker Suparcase® provides a strong mechanical hold on the tube. • Longer thread area for improved resistance to pressure and load on the ferrules. • Molybdenum disulfide-coated inverted nut helps prevent galling, provides easier assembly, and permits multiple remakes. • Long tube-support area improves resistance to vibration and line loads.

Download Catalog Here

COMMERCIAL GEAR PUMP BEARING

Parker’s 031 series fixed/positive displacement gear pumps offer high durability & resistance to oil contamination due to their cast iron, roller bearing construction, making them an ideal selection for the Vocational Truck, Winch, and Oil & Gas markets. They are available as single or multi-section pumps with an integral valve.

Technical Specifications: • Flow range to 38.4 gpm (145.4 lpm) per section • Displacements from .985 to 3.94 cir (16.2 to 64.6 cc/rev) • Operating pressures up to 200 bar (3,000 psi) • Speeds up to 2,400 rpm • Volumetric efficiencies up to 95% • CW, CCW, and Bi-rotational pumps available • SAE and SI shafts, flanges and porting available • Multiple section • Extensive integrated valve capabilities - Relief with anti-cavitation check - Priority flow control - Unloader valves - Accumulator charge (single and dual) - Two-speed valves (winches, ground drives) - Load sense priority flow divider (bolt-on) - Dry valves, HOC™ (hydraulic overspeed control), flow controls - Crossover relief valves

Download Catalog Here

F11/F12 MOTOR

Parker F11 hydraulic motor series has operating pressures up to 420 bar (6,100 psi) and speeds up to 14.000 rpm. The F11 motor is a robust design motor, and can be used in numerous applications in both open and closed loop circuits. Sizes from 5-19 cc.

Parker F12 hydraulic motor series has operating pressures up to 500 bar (7,250 psi) and speeds up to 7.300 rpm. The F12 motor is a robust design motor, and can be used in numerous applications in both open and closed loop circuits. Sizes from 30-250 cc.

Series F11
F11 is a bent-axis, fixed displacement motor/pump. It
can be used in numerous applications in both open and
closed loop circuits.
The F11 series is available in sizes 5, 6, 10, 12, 14 and
19 cc.

F11 Features
• Max intermittent pressure up to 420 bar and
continuous operating pressure up to 350 bar
• Thanks to low weight pistons and a compact design of
the rotating parts, the F11 tolerates very high speeds,
up to 14000 rpm
• CETOP, ISO, SAW and SAE versions

Series F12
F12 is a bent-axis, fixed displacement motor/pump. It
can be used in numerous applications in both open and
closed loop circuits.
The F12 series is available in sizes 30, 40, 60, 80, 90,
110, 125, 152, 162, 182 and 250 cc.

F12 Features
• Max intermittent pressure up to 480 bar and
continuous operating pressure up to 420 bar
• The 7 or 9 piston design provides high start-up torque
and smooth motor operation
• ISO, Cartridge, SAW and SAE versions

Download Catalog Here

AUTOCLAVE VALVE

Parker Autoclave’s VRMM Series micro-metering valves are designed for applications where more precise control of small flows is required than is possible with a standard regulating stem. Barrel and Thimble micrometer design permits settings to be repeated. Metering is effected by a finely tapered stem acting in a precisely mated replaceable seat. Very fine stem position is achieved utilizing a 40 TPI thread. The Barrel and Thimble are set for proper metering at the factory.

These valves are designed for metering only and cannot be used as a shutoff valve. Minimum flow is factory set and occurs at “0” position. DO NOT OPERATE THE VALVE BELOW THE ZERO POSITION OR DAMAGE WILL RESULT. When shutoff action is required, a correlated shutoff valve from Parker AE series 10V, 30VM or 60VM should be installed in series with the micro-metering valve.

Technical Specifications

  • Body Material : 316 Stainless Steel
  • Body Type : 2-Way Angle
  • Tube Size : 1/4″ Cone and Thread
  • Maximum Working Pressure (psi) : 30, 000
  • Stem Type : Reg
  • Brand : Autoclave
  • Technology : Process Control
  • Application : High Pressure Fuid Handling

Download Catalog Here
